Spectra 99

SPECTRA 99 is designed for modern high-definition audio workflows and is fully optimized for sample rates up to 96 kHz, delivering precise and stable spectral analysis in both standard and high-resolution sessions. The VST3 plugin follows the host DAW's sample rate.

At its core is a 99-Band Balanced Log-Linear Musical Layout, providing a natural and intuitive view of your mix from deep sub-bass to the highest air frequencies.

Windows only.

Key Features

• Engine: 99-Band Balanced Log-Linear Musical Layout.

• Resolution: Adaptive 4096 / 8192-Point FFT.

• Windowing: Ultra-Low Spectral Leakage Blackman Algorithm.

• Tilt Modes: 0 dB, 3 dB, 4.5 dB Reference Slopes.

• Ballistics: 100 ms, 250 ms, 350 ms, 500 ms Decay Modes.

• Precision: 32-bit floating-point (Standalone), 64-bit double-precision (VST3).

• Metering: Dual-layer LR Peak and RMS meters (background = input, top ticks = output).

• Stereo Tool: Correlation meter for width & phase monitoring.

• Safety: Output level control (Standalone).

• Formats: Standalone Application & VST3 Plugin.

• Sample Rates: 44.1–96 kHz (Standalone), Host-Dependent in VST3.

CPU-Efficient Processing

Each tool is engineered with highly optimized DSP and lightweight graphics, ensuring stable, low-latency performance—even under heavy analysis or high sample rates.

Version History

v1.4 – June 2026
• Fixed Grid Button toggling behavior (VST3) and improved grid system UI.
• Optimised performance by refactoring spectrum component.
• Added a new color selection and improved meter panel performance.

v1.3 – May 2026
• Added 350 ms option for Ballistics Decay mode.
• Removed Post Gain trim control from the VST3 version to preserve host signal flow integrity.
• Improved UI refinements for enhanced visual clarity and consistency.

v1.2 – February 2026
• Fixed bypass and on/off behaviour. Improved synchronization between host state and plugin processing to ensure correct visual and audio response.
• Improved minor UI refinements for enhanced visual clarity and consistency.

v1.1 – January 2026
• Reduced CPU Load - Optimized graphics engine for smoother performance and lower resource usage.
• Enhanced Visuals - Level meters have been recalibrated for pixel-perfect alignment.

v1.0 – Initial Release
• First public release of Spectra 99.
