Clipper 7

Clipper 7 is a precision digital clipper built around a dual-layer FFT analysis engine that monitors both input and output signals in real time. Instead of relying solely on waveform-based shaping, Clipper 7 allows users to see the spectral impact of clipping at every step — making it easier to control tonal balance, detect unwanted harmonics, and dial in musical results with confidence.

The processor includes seven unique clipping algorithms and up to 8x oversampling, providing flexible tonal options for mixing and mastering. Clipper 7 is available as both a Standalone application and a VST3 plugin.

Key Features
• Engine: Dual-Layer FFT-Driven High-Resolution Clipper.

• Clip Types: 7 distinct algorithms for tonal shaping.

• Oversampling: Up to 8x real-time oversampling for reduced aliasing.

• Analyzer: Dual-Layer Input/Output FFT display for precise harmonic monitoring
• FFT Engine: 4096 / 8192-point resolution with Blackman window.

• Response Model: Internal 4.5 dB tilt and 350 ms ballistic decay.

• Gain Structure:
- Drive: 0 to +24 dB
- Clip (Threshold): 0 to -24 dB
- Output Trim: 0 to -90 dB
• Metering: Gain Reduction meter and Dual-layer LR Peak meters
(background = input, foreground = output).

• Precision: 32-bit floating-point processing.

• Sample Rates: 44.1 - 96 kHz (Standalone), Host-Dependent in VST3.

Standalone-Only Features
• Playback: Drag & Drop loading with Loop functionality.

• Export: Render processed audio to WAV (16-bit or 24-bit).

Version History

v1.3 – June 2026
• Aligned the gain reduction meter behaviour for the processed signal.
• Replaced the Rectifier type with a high-performance Foldback clipper.
• Optimized spectrum processing and peak meter performance.
• Minor UI refinements for improved visual consistency.

v1.2 – May 2026
• Aligned the behaviour of the spectrum display and dual peak meters when bypassed. Scaled trim output to -24dB.
• Improved dual-layer spectrum resolution and standalone UI performance.

v1.1 – February 2026
• Disabled standalone native title bar maximize button to prevent UI layout issues.
• Improved standalone stability by disabling multi-instance mode to prevent potential launch conflicts.

v1.0 – Initial Release
• First public release of Clipper 7.
