Krunx-Q

Krunx-Q is a high-precision bitcrusher and sample rate reducer built around a dual-layer FFT analysis engine that monitors both input and output signals in real time. Instead of treating digital degradation as a simple destructive effect, Krunx-Q allows users to visualize the specific spectral artifacts and aliasing generated by the processing — making it easier to sculpt digital noise, manage high-frequency content, and dial in vintage character with surgical accuracy.

Key Features

• Engine: High-Precision Digital Bitcrusher with resolution-accurate quantization logic.

• Bit Depth Control: Stepped integer controls from 24-bit down to 2-bit.

• Rate Reduction: Independent sample-rate reduction stage for controlled digital aliasing.

• Oversampling: Selectable 1x, 2x, 4x, or 8x real-time oversampling for reduced aliasing.

• Analyzer: Dual-Layer Input/Output FFT display for precise harmonic monitoring.

• Response Model: Internal 4.5 dB tilt and 350 ms ballistic decay.

• Gain Structure:

- Drive: 0 to +24 dB (Pre-processing).

- Output: -24 dB to +24 dB (Post-processing).

• Metering: Dual-layer LR Peak meters (background = input, foreground = output).

• Precision: 32-bit floating-point processing.

• Sample Rates: 44.1 - 96 kHz (Standalone), Host-Dependent in VST3.

Standalone-Only Features

• Playback: Drag & Drop loading with Loop functionality.

• Export: Render processed audio to WAV (16-bit or 24-bit).

Version History

v1.3 – June 2026
• Optimized spectrum processing and peak meter performance.
• Minor UI refinements for improved visual consistency.

v1.2 – May 2026
• Aligned the behaviour of the spectrum display and dual peak meters when bypassed.
• Improved dual-layer spectrum resolution and standalone UI performance.

v1.1 – February 2026
• Disabled standalone native title bar maximize button to prevent UI layout issues.
• Improved standalone stability by disabling multi-instance mode to prevent potential launch conflicts.
• Added double click support on knobs to restore default values.

v1.0 – Initial Release
• First public release of Krunx-Q.
