MB3X Multi-Band Mastering Compressor

Multi Band Compressor Plugin by Raising Jake Studios
MB3X Multi-Band Mastering Compressor
MB3X Multi-Band Mastering Compressor by Raising Jake Studios is a Virtual Effect Audio Plugin for macOS and Windows. It functions as a VST Plugin, an Audio Units Plugin, a VST 3 Plugin and an AAX Plugin.
My KVR - Groups, Versions, & More
4 KVR members have added MB3X Multi-Band Mastering Compressor to 2 My KVR groups 5 times.
Not In Your MY KVR Groups
(or group limitation prevents versioning)

KVR Rank

Overall: 4155   3176   3970

30-Day: 5174; 7-Day: 5071; Yesterday: 10847

The MB3X Multi-Band Mastering Compressor is a plugin emulation of the hardware unit manufactured by Rocksonics Professional Audio in the mid 1990's - with BONUS features only available in the plugin.

The MB3X is a mastering grade compressor/limiter with extremely low distortion and utmost musicality. The MB3X uses multiple layers of program-dependent RMS level detectors for smooth, low distortion "musical" results while being very simple to set up and operate. The compressor has three fixed bands of compression separated by unique, constant amplitude Bessel crossovers that produce minimal phase distortion and NO pre-ringing. A single Threshold control sets the nominal compression threshold point that can be individually trimmed for each band via unique "tilting" trim controls making it extremely fast to set up.

The MB3X plugin includes many features not part of the original hardware unit including:

  • A "Hilbert" control that reduces the THD of the compressor to inaudible levels over most of the audio range - for example, THD of a 35Hz sine wave at full compression is only 0.003% with Hilbert control engaged.
  • A/B memory recall of two different sets of settings. When a project is saved in a DAW BOTH sets of controls are saved allowing further "tweaking" at a later time if desired.
  • Wet/Dry Mix controls for both the compressor and overall process for blending the compressed signal with the original source signal for parallel compression techniques.
  • Variable Saturation control that adds a touch of harmonic distortion for added presence to the signal.
  • Switchable 1dB/2dB gain ranges for the gain reduction meters.
  • Automatic mono/stereo channel switching for reduced CPU load when used on mono tracks in mixing.

Version 2 now includes:

  • "1/2-rack stacked", re-sizable GUI with automatic scaling for high DPI video monitors.
  • External Sidechain input.
  • Input level Trim control.
  • Separate Wet/Dry mix control for just the compressor section.
  • Variable Saturation with Drive and Post level controls.

The MB3X compressor can be used to automatically balance the audio spectrum in applications such as Web Radio or can be adjusted to preserve the source EQ balance when used in applications such as mastering. In either case, the compressor will bring out the details in the audio while controlling dynamics in a musically pleasing way for a "finished" sound.

MB3X is a 64-bit plugin available as VST2, VST3 and AAX for Windows PC and VST2, VST3, AAX and AU formats for Mac OS 10.11+ on Intel and Apple Silicon. Free 14-day trial demos are available for download at the RJ Studios website.
